OPTICAL
• Light Source: LED 550W
• Expected life: 20,000 hours
• Color temperature: 6000K
• Focus: High-precision glass lenses, electronic linear HD focus
• Zoom: 4° - 45°
• CRI: Ra≧70
FRAMING
•Framing: One set of full profess framing system, 120° rotation, 4 sets of blades fast movement to form geometric graphics; The graphics can be different shapes and size
GOBO
• Rotating gobo: 7 interchangeable gobos, CW/CCW rotation, variable speed, 16-bit control.
• Static gobo: 6 static gobos + 1 animation gobo, CW/CCW rotation, variable speed
COLOR
•CMY / CTO: CMY linear infinity color mixing, macros; CTO linear color temperature adjustment (6000k-2700k)
•Color wheel: 1 wheel with 9 colors, CW/CCW rainbow effect, split color and linear control
ELECTRICAL
• Input: AC 100V-240V 50/60Hz
• DMX data in/out: IP67 seetronic XLR
• Power socket: IP67
CONTROL/PROGRAMMING
• Control channel: 36/33/52
• Protocol: DMX512 RDM
• Display: LCD
DYNAMIC EFFECTS
• Pan/tilt: 540°/270°, 16-bit control and automatic return correction
• Iris: 5-100% linear control with macro function
• Strobe: 1-25Hz fast strobe, synchronized and asynchronous, pulse effects
• Frost: 1 independent frost filter
• Dimmer: 0-100% linear electronic dimming, 3 built-in dimming modes.
• Prism: 4 facets prism with bi-directional rotation
PHYSICAL
• Weight: 28kg
• IP rating: IP66
Technical Specification
Photometric Diagram
Gobos & Colours
Exterior Dimensions
Accessories
Downloads
Product Video
GTD-F6 II BSWP
